Motion estimation in PET-MRI based on dual registration: preliminary results for human data

  • Michael Fieseler1, 2,
  • Thomas Kösters3,
  • Christopher Glielmi4,
  • Fernando Boada3,
  • David Faul4,
  • Matthias Fenchel5,
  • Robert Grimm6,
  • Xiaoyi Jiang1, 2 and
  • Klaus P Schäfers1
EJNMMI Physics20141(Suppl 1):A39

DOI: 10.1186/2197-7364-1-S1-A39

Published: 29 July 2014

In current motion correction approaches in PET-MRI, motion information from PET data is neglected. We present an approach where PET and MRI data are used for motion estimation simultaneously. The presented approach has been evaluated on phantom data before [1]. Here, we present first results for human PET-MRI data.

The registration functional for dual registration is given by

Here, RMR and RPET denote two reference volumes and TMR and TPET the template volumes to be registered, D is a distance functional, and S is a regularizer. The scalar value β allows to weight the influence of the data term for PET [1]. The functional has been implemented using the FAIR toolbox [3].

Five patients were scanned following a clinical FDG scan. A self-gated radial VIBE sequence [2] and PET Listmode data were acquired. The datasets were re-binned into 5 coinciding PET and MRI phases (gates).

Registration were computed for β {0, 0.5, 1, 2}, α was chosen empirically as α = 20.

Correlation coefficients were computed for the heart region.

In Figure 2a we show correlation values for each gate of dataset 4. In all gates the correlation of the PET data is improved using the joint motion estimation approach using a weight of β = 2. In 2b average correlation values of all gates are shown for all datasets processed.
Figure 1

Overlay of PET and MR data for dataset 4, first respiratory phase (gate).

Figure 2

Correlation values for PET data. (a) Correlation values for the heart region in gates 2 to 5 for dataset number 4. (b) Average correlation values for all patients

We have shown that using a joint motion estimation approach the correlation of PET data is improved compared to an estimation of the motion solely on MRI data. Currently, we are evaluating motion-correcting reconstructions using the motion estimates from the proposed method.

Authors’ Affiliations

European Institute for Molecular Imaging, University of Münster
Department of Computer Science, University of Münster
Center for Advanced Imaging Innovation and Research, NYU Langone Medical Center
Siemens Medical Solutions USA
Siemens AG, Healthcare Sector
Pattern Recognition Lab, University of Erlangen-Nürnberg


  1. Fieseler M, Gigengack F, Jiang X, Schäfers KP: Motion correction of whole-body PET data with a joint PET-MRI registration functional. BioMedical Engineering OnLine 2014,13(Suppl 1):S2. 10.1186/1475-925X-13-S1-S2PubMed CentralPubMedView ArticleGoogle Scholar
  2. Grimm R, Fürst S, Dregely I, Forman C, Hutter JM, Ziegler SI, Nekolla S, Kiefer B, Schwaiger M, Hornegger J, et al.: Self-gated radial MRI for respiratory motion compensation on hybrid PET/MR systems. Medical Image Computing and Computer-Assisted Intervention– MICCAI 2013, 17–24.Google Scholar
  3. Modersitzki J: Fair: Flexible Algorithms for Image Registration (Fundamentals of Algorithms). In Society for Industrial and Applied Mathematics. Philadelphia; 2009.Google Scholar
